This is one of the widely used fasteners. Bolt is made from a thin rod of metal. On its upper side, different types of heads are made to fix them. On the remaining part or a part of it, there are threads. From this side, it can be fixed in a job or a nut can be fitted figure shows a nut and a bolt.
Bolts come in a variety of types and are used in many applications. Here are a few of the most well-liked ones:
1 Hexagonal Bolt
Hex bolts are a specific type of threaded bolt defined by their head’s six-sided hexagonal shape. Hex bolts are suitable for use in a variety of applications, typically in machinery and construction, and can be fully or partially threaded.
2 Cheese Head Bolt
Cheese head slotted screws have cylinder-shaped sides, a flat top disc, and a flat bearing surface. They can be identified by the type of head they have, which has a slot drive and a head height that is roughly half of its diameter.
3 “T” Head Bolt
T-Head bolts also referred to as Hammer-Head bolts, have a variety of uses, including fastening lift guide rails.
4 Eye Bolt
Bolts with loops on one end are known as eye bolts. They are employed to firmly fasten a securing eye to a structure, allowing ropes or cables to be tied to it.
5 Square Bolt
Similar to hex cap screws, square head bolts have a square head with four sides as opposed to a hexagonal head with six sides.
6 Headless Taper Bolt
This is applied to substantial marine shaft couplings. It lacks a head and has a tapered shank.
7 Countersunk Head Bolt
A countersunk screw, also referred to as a flat-heat screw, is a particular type of screw that is intended to rest flush with the object or surface into which it is inserted.
Bolts Specification:
STANDARD SIZE: M3 to M56
LENGTH: 6 milimeter-500 millimetre
STANDARD: ISO 4017, DIN931, DIN, ANSI, GB5783, ASTM, JIS, EN, AS
THE BOLTS ARE AVAILABLE IN VARIOUS MATERIALS
INCLUDING STAINLESS STEEL ,DUPLEX STEEL ,SUPER DUPLEX STEEL ,
NICKEL ALLOY ,INCONEL ,FERROALLOY ,TITANIUM & HASTALLOY
